CCD Camera Vinyl Cutter
OEM & ODM producer for Phone protective film cutting machine, vinyl cutter, label cutter!
Language
OEM & ODM producer for Phone protective film cutting machine, vinyl cutter, label cutter!
1. Camera scan,scan various materials
2. High accuracy machine structure allows to cut 2mm letters without distortion
3. Support CoreIDRAW output directly,optional signmaster/flexisign/Artcut
Advantages
1. Full large touch screen
① High sensitivity
② Simple use, straight forward operation
③ With multiple language
④ Powerful function as repeat - repeat cut the last job
2. High precision steel axes
The paper feeding of the machine is accurate and error free.
3. Paper feeding pinch roller
⑴ Bespoke
⑵ High temperature and wear resistance
⑶ Long service life
4. Teneth imported blade
Used for cutting self-adhesive, cardboard,
film, sandblasting paper, reflective film
and other materials
Technical Specifications
Model | MC600 |
Control panel | 4.3 inch touch screen |
Driver | High speed, big power step motor |
Maximum cutting area | 600mm |
Cutting forth | 10-1000g |
Cutting speed | 1000mm/s |
Mechanical precision | 0.025mm |
Repeatable precision | <+-0.025mm |
Plotter pen | All types diameter 11.4mm plotter pen |
Plotter instruction | DM-PL/HP-GL |
Interface | USB/U disk/Serial port |
Knife | Teneth imported blade |
Power supply | AC220V, 50-60Hz |
Power consumption | <80W |
Package size | 1000*720*380mm |
Gross weight | 24kg |
Warranty | 1 Year |
Product Application
1. The computer carving machine can be used in the wall sticker industry in the current market to engrave various patterns of flowers, grass, animals, switch stickers, etc.
2. In the banner printing industry, it is used to engrave transfer paper, silk screen, etc.
3. The output device used for drawing in the garment processing industry can replace the plotter.
4. The sandblasting and engraving industry is used to engrave special film for sandblasting. It is suitable for advertising production, light box production, woven bag printing, reflective film engraving, CAD sketch drawing, 3M reflective film engraving, mobile phone beauty stickers, car stickers, timely stickers, dust-proof cloth engraving, banner production, exhibition board production, glass spray Sand and so on.
