1.Adopt servo motor driver mode,with intelligent AI algorithm, to bring high quality experience for shaped cutting.
2.Camera positioning tracking system,accurate and sensitive,identify cutting all kinds of shaped patterns
3.Patented flatbed structure design,multi-zone vacuum adsorption design,low voice,strong suction power.
Advantages
1. 4.3inch HD screen
① High sensitivity
② Simple use, straight forward operation
③ With multiple language
④ Powerful function as repeat - repeat cut the last job
2. Double heads
Two cutter heads, can be exchanged for full cutting and half cutting, and can also be creasing
3. Barometer
Adjust air pressure according to different material thickness
4. Multiple connection
U disk/USB/WIFI(optional)
Technical Specifications
Model | FC7090U |
Control panel | 4.3 inch touch screen |
Driver | High speed, big power servo motor |
Maximum cutting area | 700mm |
Cutting forth | 10-1000g |
Cutting speed | 1000mm/s |
Mechanical precision | 0.025mm |
Repeatable precision | <+-0.025mm |
Plotter pen | All types diameter 11.4mm plotter pen |
Plotter instruction | DM-PL/HP-GL |
Interface | USB/U disk/WIFI |
Knife | Teneth imported blade |
Power supply | AC220V, 50-60Hz |
Power consumption | <80W |
Package size | 1600*1300*1100mm |
Gross weight | 240kg |
Warranty | 1 Year |
Features:
1. Using imported reflective film blade, it can cut materials within one millimeter (crystal labels, PVC, DTF materials, cartons, etc.)
2. Double-headed carriage with camera function, capable of half-cutting, full-cutting, and indentation
3. Our machine adopts imported guide rail, which has high precision and long service life
4. High-grade steel wire belt, strong stretchability, and not easy to break
5. The whole machine adopts a vacuum adsorption device, which is adjusted according to the thickness of the material and the air pressure gauge. so long without going astray
6. Support AI,CAD,CDR,SIGNMASTER and so on
What can we do with machine?
Box cutting,sticker half-cut,crystal label,PVC,PPF,DTF material.
